Usually rubber cables are made of Styrene-Butadiene Rubber, Butyl, EPR or Ethylene Propylene Rubber but we, Amex wires and cables, make our rubber using elastomer material such as ethylene propylene rubber (EPR), polychloroprene (PCP), chlorosulphoneted polyethylene (CSP), nitrile rubber/PVC blends and silicon to assure resistance against heat, oil and fire. Elastomeric compounds for sheathing and insulating of cables are designed to meet the requirements of IS 6380, BS 6899, IEC 60502, and other international specification..
* VIR / TRS CABLE
* EPR / PCP CABLE
* ERP / CSP CABLE
* MAGNET CABLE
* HIGH MAST CABLE
General Construction (Conforming to IS 9968 Part 1) |
|
Conductor |
Annealed tinned Copper wires Solid (Class 1), Stranded (Class 2), flexible (Class 5) complying with the requirement of IS 8130-1984 |
Seperator Tape |
Suitable material separator tape may be applied over the conductor |
Insulation |
General service elastomer compound Type IE1 of IS 6380-1984 |
Core Identification |
Colored insulation, Nos. PE tape, Colored proofed tape, Nos. printing |
Fillers |
Natural or synthetic fibers or elastomer suitable for the operating temperature and compatible with the insulating material |
Sheath |
General service sheath Type SE1/SE2 of IS 6380-1984 |
Working Temperature of Commonly used Elastomeric Insulating and Sheathing Material |
|
RUBBER CABLES, CABLES for HIGH-MAST, VIR / TRS. ERP / PCP / CSP CABLES, CRANE MAGNET CABLE, SILICON CABLES, FIBRE GLASS CABLES, HEAT RESISTANCE CABLES, TEFLON / PTFE WIRES, COMPENSATING CABLES (J.K.R.S.TYPE)UPTO 600"
